Shopping around for an electric water heating system that complements your busy 21st century lifestyle? One that delivers instant hot water to all areas of your home or workplace, is easy to install, and only expends the necessary amount of energy required to get the job done? If the answer is yes, the MicroHeat CFEWH Three Phase electric water heater might be the perfect solution.
This highly effective and efficient 3 Phase hot water system features no heating elements or a tank, but does boast the most cutting-edge technology including full digital control and ‘set and forget’ temperature regulation. Discover the CFEWH Series Three Phase electric water heater from MicroHeat today.
Three Phase Solution – CFEWH Series 2 Features
Noticeably more powerful than our single phase heating system, our 3 Phase instantaneous water heater boasts some impressive features. These include:
- CFEWH Series 2 power rating available in power rating from 15kW, 18kW, 21kW, 24kW, 27kW to 30 kW
- The Footprint(A4) same as the CFEWH Series 1
- Delivers minimum flow rate of 1.5 LPM with no maximum flow rate restriction
- Options for units to be maximum settable from 20°C up to 65°C
Applications include but are not limited to:
- Hand basins –multiple
- Showers
- Kitchens / laundries
- Boosting for existing hot water installation – such as tanks or to increase water temperatures in a ring main at the point of use.
- Apartments / units
- Residential homes
- Commercial water heating solutions
- Water heating for factories
- Solar hot water system boosting
The Three Phase water heater comes ready to install in homes, apartments (high and low rise), office complexes, aged care facilities, shopping malls, and a wealth of other public and privately owned properties Melbourne wide. Contact MicroHeat today and experience the multitude of features and benefits of this revolutionary 3 Phase tankless water heater for yourself!
CFEWH SERIES Hot Water Output Temperatures/Flow Rate Tables
The incoming water temperature of our 3 Phase instant hot water heaters will vary during summer and winter. The following tables show the hot water flow rates at various inbound water temperatures for each of the 3 Phase hot water heater models available.
| OUTPUT WATER TEMPERATURE 50°C | ||||
| Maximum Litres per minute with incoming water temperature | ||||
| Incoming Water temp. | Series 2 - 18 415 V 18 kW | Series 2 - 21 415 V 21 kW | Series 2-24 415 V 24 kW | Series 2-30 415 V 30 kW |
| 10°C | 6.4 | 7.5 | 8.6 | 10.7 |
| 15°C | 7.4 | 8.6 | 9.8 | 12.3 |
| 20°C | 8.6 | 10 | 11.5 | 14.3 |
| 25°C | 10.3 | 12 | 13.8 | 17.2 |
| 30°C | 12.9 | 15 | 17.2 | 21.0 |
| Technical Specifications | THREE PHASE |
| CFEWH SERIES 2-15 / 18 / 21 / 24 / 27 / 30 | |
| Electrical Connection In accordance with AS/NZ 3000 electrical regulations | |
| Power supply | Three Phase |
| Rated Power (kW) | 15, 18, 21, 24, 27, 30 kW |
| Voltage (VAC) | 415 |
| Rated AMPS (A) | 20, 25, 29, 33, 38, 42 A ( Hard Wired Circuits) |
| Frequency (Hz) | 50/60 |
| Unit Parameters | |
| Max. temp. settable options °C | 50 or 65°C |
| Switch on Flow Rate | 1.5 LPM |
| System Type | Continuous Flow Electric Water Heater(CFEWH)- Electric Instantaneous / Tankless |
| Max. Operating Line Pressure | 10 bar / 1MPa |
| Min. Operating Line Pressure | 1.5 bar / 0.15 MPa |
| Dimensions | H 315mm x W 210mm x D 170mm |
| Heating Method | Optimized Direct Energy Transfer - Full Digital controlled water heating |
| Nominal Capacity (ml) | 382 ml |
| Standards | |
| Water Regualtion | WaterMark License WM-022136, AS/NZS 4020 & AS/NZS 3500* |
| Electrical Safety | AS/NZS 60335.2.35 / IEC 60335.2.35 |
| EMC | CE/C-Tick |
* In accordance with AS 3500 Section 1.9.2 and Section 1.9.3. No tempering or thermostatic mixing
valves are required for personal hygiene sanitary fixtures other than stipulated in Section 1.9.2 (a).
Important: “Electric instantaneous water heaters may draw high levels of power, but only for relatively very short periods of time when compared to electric storage tank water heaters. The wiring rules accomodate this difference by applying a calculation where the power demand requirement can be reduced by as much as 66%.”
Refer: AS/NZS 3000:2007 Electrical installation (Wiring Rules), Appendix C, Circuit Arrangements.
Installation instructions must be followed correctly as per CFEWH Installation manual.
Installation must conform to current electrical wiring and plumbing standards.
Installation Warning – Plumbing
Installation Warning – Three Phase Electrical Connection
